Reci hobby Chinese co2 laser cutting engraving machine laser engraver for marble foam cardboard

FOB Reference Price:Get Latest Price
$2,099.00 - $2,399.00 / Sets | 1 Set/Sets (Min. Order)
Power(W):
80W/100W
Model Number:
DW-6090
Lead Time:
Quantity(Sets) 1 - 5 >5
Est. Time(days) 5 Negotiable
Customization:
Customized logo (Min. Order: 5 Sets)
Customized packaging (Min. Order: 5 Sets)

More

Graphic customization (Min. Order: 5 Sets) Less
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Free spare parts
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
Laser Type:
CO2
Engraving Speed:
0-60000mm/min
Graphic Format Supported:
AI, BMP, DST, DWG, DXF, DXP
Application:
Laser Engraving
Engraving Area:
600*900mm
Condition:
New
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Place of Origin:
Henan, China
Brand Name:
DOWIN
Dimension(L*W*H):
1650*1250*1470mm
Certification:
CE, ISO, CCC
Warranty:
2 Years
Product name:
Reci hobby Chinese laser cutting machine for marble foam cardboard
Laser tube:
CO2 Laser Tube
Keywords:
Laser Engraving Cutting Machine
Power supply:
220V±10% /50HZ , 110V±10%//60HZ
Function:
Cutting Engraving Non-metal Materials
Model:
DW-6090
Laser power:
80w/100w
Type:
Water Cooling CO2 Laser Engraving Machines
Color:
Blue-White
Software:
RUIDA
Supply Ability
Supply Ability:
1000 Set/Sets per Month Reci hobby Chinese co2 laser cutting machine for marble foam car
Packaging & Delivery
Packaging Details
Reci hobby Chinese co2 laser cutting machine for marble foam cardboard
wooden box
Port
Qingdao, Beijing , Tianjin, Shanghai, other
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 5 To be negotiated
Video Description

Reci hobby Chinese co2 laser cutting engraving machine laser engraver for marble foam cardboard



Technical Parameters
ModelDW-6090
Processing area600*900mm
Laser tube80W(Option100W)
Engraving speed0-60000mm/min
Cutting speed0-10000mm/min
Cutting thickness20mm Acrylic
Minimum  characterLetter 1.0 x 1.0mm
Support graphic formatAI, PLT,BMP, DST, DWG, DXF,
Resolution ratio<0.01mm
Location precision<0.01mm
Power supply220V±10% /50HZ , 110V±10%//60HZ
Operating temperature5%-95% Free of condensed water
Laser tube's life10000 hours
InterfaceUSB
Control systemRUIDA
Packing Weight240KG
Packing size165*125*147cm
Delivery Time7 Working days after payment received
Honey or knife table
Industry Chiller
Exhaust fan & air pump
Product Description

Reci hobby Chinese co2 laser cutting engraving machine laser engraver for marble foam cardboard

1) Red dot positioning Synchronize with the laser, which make the operation more convenient.
2) Ensure the accuracy higher than similar models on the market.
3) Knives and cellular dual cutting platform can meet the cut requirement of a variety of products.
4) DSP control system and Ruida board can ensure the engraving and cutting task completed quickly at one time.
5) Make the processing of various thickness material more convenient.
6) Wide range of applications: Advertising industry, Office industry, Packing industry, Gift industry, Decoration industry, Printing Industry.

--Sketch map of Optical system

The laser beam is from laser tube, then reflecting mirrors and focus lens,

as following



Detailed Images

Reci hobby Chinese co2 laser cutting machine for marble foam cardboard

Focus on laser engraving machine more than 10 years ,we have our own factory ,welcome to visit at any time.

# Voltage: 110v-220v/50~60hz

#  Leadshine M860 57 step motor and Leadshine driver

# Co2 tube

# Original Ruida 6442s control system

# Honeycomb or Knife table

# Original square rails imported from Taiwan

# Water protection system

# Ruida wifi controler

# Red light point

# Water chiller CW3000 CW5000 CW-5200

# Big power Air pump and 550W exhaust fan




Application & Sample

It is widely used in electronic, craft and gift, garment, leather, toy, computerized embroidery, packing and printing, shoe making, furniture, advertising industries ect.

Reci hobby Chinese co2 laser cutting machine for marble foam cardboard Application:

1) Acrylic engraving and cutting

2) Wood/MDF engraving and cutting

3) Leather engraving and cutting

4)Paper engraving and cutting

5) Rubber sheet engraving and cutting

6) Double color board & coated board engraving

7) Marble and stone engraving

8) Cylinder engraving

9)Thin metal board cutting

10)and other non-metal materials.

Please refer to those info to choose correct laser power or tell us what materails and thickness you want to cut.
