Three in one channel letter automatic metal sheet angle steel bending slotting notching machine slot

FOB Reference Price:Get Latest Price
$6,000.00 - $8,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 3 >3
Est. Time(days) 10 Negotiable
Customized logo (Min. Order: 5 Sets)
Customized packaging (Min. Order: 5 Sets)
Report Suspicious Activity
Quick Details
1 year, 1 Year
After-sales Service Provided:
Online support, Overseas service center available
Place of Origin:
Henan, China (Mainland)
Brand Name:
Extra Services:
Slotting & Notching
Material / Metal Processed:
Stainless steel, iron, aluminum, aluminum profiles
Raw Material:
Steel Bar
Machine Type:
Bending Machine
Full Function Bending Machine
480 kg, 480KG
cnc bending machine
Motor power:
3.0 KW
Input Fill Format:
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard wooden case
Lead Time :
Quantity(Sets) 1 - 3 >3
Est. Time(days) 10 To be negotiated
Video Description
Product Description

Three in one channel letter automatic metal sheet angle steel bending slotting notching machine slot.

Feeding system
Rolling-typed continuous feeding device
Slotting System
Plane alloy knife , double-knife slotting system
Bending System
Double blade alternate bending system
Suitable Material
Stainless steel, iron, flat aluminum, aluminum profiles
Material Height
Material Thickness
Stainless steel, iron, flat aluminum≤1.2mm aluminum profiles≤1.0mm
Min. Bending Angle
Size Accuracy
File Format
L2571mm x W800mm x H1550mm
Air Supply
Total Weight

Main Features of this three in one channel letter automatic metal sheet angle steel bending slotting notching machine slot.

1.Plate material and Aluminum Profiles integrated processing.

2. it can effectively reduce the material waste during using the plate material.

3. Servo drive + high quality ball screw and linear guide configuration makes the feeding smooth and steady. Effective control the material deformation

4. The closed loop control of the length encoder and system makes the products perfect match with the source file.

5. The products have a lot of external control institution so that the products are simple, safe, accuracy and easy to use.

6. The 4-axis control system of feeding, slotting, slotting height and bending has improved processing simple, fast and stability.

7. because of the full range of products and a variety of flexible application of the products provided service, make sure you take time for future production needs.

8. With the ability to process profiles under the same platform, there is no need to replace hardware for sheet and profile processing. The minimum bending radius is 6mm.

9. According to the internal and external arc changes of the machining pattern, the corresponding bending knife is automatically switched for bending. During the switching process, the reverse knife automatically collects the tool magazine to avoid the phenomenon that the bending knife interferes with the forming angle, and the molding performance for the small arc and small angle is excellent.

Product Application.

Advertising industry, such as logos, signs, neon signs, billboards, light boxes production, outdoor advertising and other advertising production.

Detailed Images

Material pre-straightening system

For the deformation problem of the coil itself, the multi-axis material pre-straightening system can be adjusted freely according to the thickness of the sheet, and the material is straightened in advance at the beginning of the processing, so that the processing quality can be improved.

Bending part

Double blade alternate bending system, special designed bending tools rod and tool edge structure, capable of processing with plate and profile. Better choice for small angle and radian bending

Blades Part

Double-cutter slotting, using plane cutter for Galvanized sheet and Stainless steel, using milling cutter for Aluminum plate and Aluminum profiles

Feeding part.

Similarly adopt the manipulator typed feeding design, and it can effectively reduce the material waste.

Main Features.

1.For the same graphics processing the consistency achieved to 99% For the batch words producing even more advantages.
2.With the ability to process profiles, there is no need to replace hardware for sheet and profile processing. The minimum bending radius is 6mm.
3.High degree of Forming ,It can match with the panel which produced by all kinds of cutting equipment and the matching degree is more than 90%.

Our Service

After-Sales Service

1.Within 7 days since your local customs clearance: if the machine's any part has any problems, we will change it free.

2.Exceed 7 days since your local customs clearance but within warranty period if the machine parts have any problems, we can change the old machine parts to new ones free, but you should pay all the shipping cost.

3.Machine Standard production One Year Warranty

4.Exceed one year warranty period if the machine parts have any problems, we can offer new machine parts with cost price and you also should pay all the shipping cost.

5.We offer 24 hours technical support by call, email.

6.Our technician can give you remote guide online(Skype / MSN/What's app/viber/Tel/Etc) if you have any question.

7.Machine has been adjusted before delivery, operation disk/CD was included in the delivery.

8.We have manual instruction and CD (Guiding Videos) for software Installation, operation and machine's using and maintenance.

Our Company

Company information.

Dowin signs tech Co., Ltd. is a collection of research and development, production and sales of integrated enterprise automatic bending machine word slotting machine and production of various laser equipment, such as laser welding machine.  Also our service support various languages, like English, Spanish, Russian, and so on. Meanwhile, customized equipment are available according to different requirements. Within the automatic bending and laser welding field, Dowinlaser has passed CE and FDA qualifications. Which assures high-efficient production and products' reliability. After years of hard work, Dowinlaser's products have made presence in more than 100 Countries such as North America, West Europe, South Asia, South America and Mid East etc.. Facing the chances and challenges of Global Economic Integration, as well as being offered with opportunities of Knowledge Economy Era, brave and passionate, initiatively implement the enterprise management policy: "Scientific Management, Continuous Improvement, Rapid Development, Credit First, Quality First". We aim to be a professional branding, and International suppliers for various industrial solutions.

Packing & Delivery


External packaging : standard wooden case

Internal packaging : Stretchy film and plastic film for humidity
we can pack it according to customers special request


Lead Time :7-10 days after confirm your order and payment
We cooperate with SINOTRANS company whose experience in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries.

1). When can I get the quotation ?

We uauslly quotion within 24 hours after we get your inquiry on the Alibaba, if you are urgent to get the machine price, please call us or tell us in your email so that we will regard your inquiry priority.

2). How can I get the sample to cheack your quality ?

If you want to welding sample to check the quality, please kindly send us the sample for testing.

3). How long can I expect to get the sample ?

We will ensure welding samples will be done within 2 days once we received the sample form your side.

4). QC Team

Our Group consists of professional people to ensure 100% products high quality.

5)Will the package be damaged during transportation?

Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe transportation. We have exported to 180 countries worldwide. So please don't worry, you will receive the parcel in good condition.

6)How to instill and run the machine?

Our technician has installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. 95% customers can learn by themselves.

7) How can I do if the machine goes wrong?

If confronted with such problems, online service is offered, you could contact our sales. Also we offer engineer delivery service. Please contact us asap and don't try to fix the machine by yourself or someone else. We will respond within 12 hours as quick as wo can to solve it for you.
