CNC wood router engraving and cutting machine factory price

FOB Reference Price:Get Latest Price
$16,000.00 - $23,500.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
DW-T5
Report Suspicious Activity
Overview
Quick Details
Condition:
New
CNC or Not:
CNC
Place of Origin:
Henan, China
Brand Name:
DOWIN
Voltage:
AC380V/50/60Hz,3PH
Dimension(L*W*H):
3710*2250*2300mm
Certification:
CE ISO FDA
Warranty:
1 year
After-sales Service Provided:
Online support, Engineers available to service machinery overseas
Control system:
NC Studio
Spindle:
9.0KW Air Cooling Spindle
Motor:
Servo Motor
Product name:
ATC CNC Wood Cutting Machine
Application:
Wood Cutting
Name:
Wood cutting machine and engraving machine
Key words:
Wood cutting engraver
Machine type:
Wood Cutting Machine
Item:
Wood cutting CNC router
Power(W):
9.0KW
Weight:
1800KG
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
Sea worthy wooden package
Port
Qingdao/shanghai/Ningbo/ect
Video Description

CNC wood router engraving and cutting machine factory price wood cutting machine



Wood cutting machine main features:

* Heavy duty machine body, welding by thick steel tube.High-performance all-round machinery with extraordinary value, but at a very economical price. With linear tool hanger, constructed with world-class components, consistent high performance.

* Featuring 9.0KW pindle motor andhigh frequency air-cooling electronic spindle and servo system .

* Vacuum table using high-density (1.3-1.45g/cm) material with great suction strength, comfortably

    accommodating all sizes of work piece.

*NC studio controller(Option Taiwan SYNTEC)—enabling this product to accomplish multi-layer 3D job, cutting, engraving, milling, all at ease.



Wood cutting machine application: Well-suited for processing panel, insulating materials, plastic, epoxy resin, carbon mixed compound, wood panel, three-dimensional wave board processing screen, handicraft fan window processing. Cutting, engraving, routing, drilling on cabinet doors, solid wood door, complex wood door, Paint-free door.

PVC, density board, stone, organic glass, soft metals like aluminum and copper, etc.



Other Industry: make building models, wood mold, air wooden mold, propeller, automotive foam mold. Shaping three-dimensional surfaces such as violin, musical instruments and so on



Wood cutting machine standard parameter:

Number

Description

Parameter

1

Dimension & Working Area

3710*2250*2300mm

1220*2440*200mm

2

X,Y,Z Traveling Positioning Accuracy

±0.03mm

3

X,Y,Z Repositioning Accuracy

±0.03mm

4

Table Surface

Vacuum and T-slot working table

5

Vacuum pump

Yes

7.5Kw vacuum pump

6

X, Y Structure

Helical Rack and Pinion Drive, Hiwin Rail Linear Bearings

7

Z Structure

Hiwin Rail Linear Bearings and Ball Screw

8

Spindle Power

9.0kw JST ATC air cooling spindle

9

Spindle Speed

0-24000RPM

10

ATC number

12 pieces auto changing tools

11

Max. Rapid Travel Rate

33000mm/min

12

Max. Working Speed

25000mm/min

   13

Drive Motors

1.5Kw high precision servo motor

14

Working Voltage

AC380V/50/60Hz,3PH (Option: 220V)

15

Command Language

G Code

16

Operating System

NC Studio control system

17

Inverter

Fuling DZB inverter

18

Dust collector

Yes

Two bags dust collector

19

Oil lubrication system

Yes

20

X,Y Resolution

<0.01mm

21

Software  Compatibility

Alphacam/Type3/UcancameV9 /Artcam

22

Running Environment  Temperature

0 - 45 Centigrade

23

Relative Humidity

30% - 75%

24

Total Power Consumption

(With Spindle)  15Kw

25

Optional Parts

1.Spindle : 9.0kw HSD ATC air cooling spindle

2. Driver motor :Yaskawa servo motor)

3.Inverter: Taiwan DELTA

3. Control System :Taiwan SYNTEC/EtherCAT

26

Warranty

1 year



*All of these models can be customized according to customer requirements.

 CNC wood router engraving and cutting machine factory price.

1.Tool setting gauge to set Tool position easily and correctly

2.Integrated Z ball screw system make sure high precision in time long run



CNC wood router engraving and wood cutting machine factory

High precision square rails and gear transmission system

1.Double bags dust collector

2.PC based NC Studio Controller with friendlier Human& machine interface/HMI, fully executed with computer. It well realizes high-speed and high-precision motion control

CNC wood router engraving and cutting machine.

Offer Zone adjustable Vacuum table with 7.5Kw strong power Vacuum table.

Electric Cabinet All the electrical components are housed and wired in a mobile, double door electrical enclosure. This allows for easy access and service when needed. Every wire is tagged so that when service is required, the customer can easily navigate the cabinet.

Straight line Auto changing tool moving with Gantry ,make it fastest to change tool ,only need 3seconds.

About us.
Dowin signs tech Co., Ltd. specializes in R&D and production of various laser equipment, CNC Router, Dowin has passed CE and FDA qualifications. Facing the chances and challenges of Global Economic Integration, as well as being offered with opportunities of Knowledge Economy Era, brave and passionate, initiatively implement the enterprise management policy: "Scientific Management, Continuous Improvement, Rapid Development, Credit First, Quality First". We aim to be a professional, branding, and International suppliers for various industrial solutions.
Quality and credit goes all the way. Dowin a company surviving fierce market competition, has very strong national culture, and develops shoulder by shoulder with the world and this Era. We are determined to achieve our dreams step by step with the advantages of high technology.

 Our service:

After service and Guaranty of our factory:
1. 2 years quality guaranty, the machine with main parts(excluding the consumables)shall be changed free of charge when if any problem during the warranty period.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. 18 hours on line service and email each day, free technical support.
5. Machine has been adjusted before delivery.We will take machine photos and make machine working image for you ,after getting your agreement ,then we will book a ship.
6. provide technical services to the door(We have professional engineers to offer
machine installation commissioning and maintenance) if customers pay the charges of ticket.
7. if you have any problem during your use.you need our technician to judge
where the problem is and help you to solve it. We can provide team viewer and
skype with can till all of your problems solved.

Package:

The advantages of Plywood Case Package:
Firstly, plywood case, its compressive strength and bearing quality is better, is the market of choice for the goods of high-weight packaging
Secondly , the board area is big, the soil structure is good,and operational process is simple,So itis better in leakproofness and waterproof.
Thirdly , when importing the plywood case is with fumigation-free , the procedure is simple.
